Go2 Remote Control 100 Meters Ultra-long Control Distance，Reliable and Durable. 1.Charging voltage: 5V 2.Charging current: 2A 3.Frequency: 2.4GHz 4.Communication mode: digital transmission module, Bluetooth 5.Running time: 4.5h 6.Remote control distance: more than 100m

1. Degree of freedom: 6 2. Load: 500g (ideal weight) 3. Maximum arm span 600mm (excluding the length of the clamping jaws, subject to minor variations for subsequent structural changes); 715mm (including the length of the jaws, subsequent structural changes may have a small change)" 4. Power Requirement: 24V 2.5A (MAX 5A) Interface: DC5.5-2.1 Power: 60W 5. Control interface: control communication interface RJ45 (ETH)

1.Charging voltage: 33.6V 2.Charging current: 9A 3.Working environment temperature: 5℃-40℃ 4.Storage Temperature: 22℃-28℃. 5.Relative humidity: ≤95%. 6. Must use together with Go2 EDU Plus (Mid-360 LiDAR) or Go2 EDU Plus (XT16 LiDAR)

The GO-M8010-6 permanent magnet synchronous motor is designed for high-performance robots and provides a strong driving force with a high level of integration.

Scanning distance: 30m(@90% reflectivity); 15m(@10% reflectivity) Measurement accuracy: ±2.0cm Nearbyblind area: 0.05m Sampling frequency: 43200points/s Effective frequency: 21600points/s Circumferential scanning frequency: 11Hz Vertical scanning frequency: 180Hz Communication interface: TTL UART IMU: 3-axis acceleration +3-axis gyroscope Human eye safety level: Class 1(IEC60825-1:2014) Human eye safety

Scanning distance: 20m(@90% reflectivity); 10m(@10% reflectivity) Measurement accuracy: ±2.0cm Nearbyblind area: 0.05m Sampling frequency: 43200points/s Effective frequency: 21600points/s Circumferential scanning frequency: 11Hz Vertical scanning frequency: 180Hz Communication interface: TTL UART IMU: 3-axis acceleration +3-axis gyroscope Human eye safety level: Class 1(IEC60825-1:2014) Human eye safety

1. Material: natural rubber + high strength material 2. 1 pair, 2 units

1. Product size: 210mm*108mm*48.2mm 2. Input power supply: 100-240V~50/60Hz 4A 350VA 3. Output power supply: 34.0V, 3.5A, 119.0W 4. Standard battery charging time: 2h 5.Long life battery charging time: 4h

1. Product size: 120mm*80mm*182mm 2.Rated voltage: DC 29.6V 3.Charging limit voltage: DC 33.6V 4.Charging current: 3.5A 5.Rated capacity: 8000mAh, 236.8Wh 6.Standard: IS 16046(Part 2)/IEC 62133-2 7.Self-developed battery management system (BMS) 8.Functions: power display, battery storage self-discharge protection, balance charging protection, overcharge protection, overcharge protection, over-discharge protection, short-circuit protection, battery load detection protection.

Go2 Battery Fast Charging, Long Endurance Provide Strong Power to Your Robots 1. Product size: 120mm*80mm*182mm 2.Rated voltage: DC 28.8V 3.Charging limiting voltage: DC 33.6V 4.Charging current: 9A 5.Rated capacity: 15000mAh, 432Wh 6.Standard: IS 16046(Part 2)/IEC 62133-2 7.Self-developed battery management system (BMS) 8.Functions: power display, battery storage self-discharge protection, balance charging protection, overcharge protection, overcharge protection, over-discharge protection, short-circuit protection, battery load detection protection

1. Product size: 210mm*108mm*48.2mm 2. Input power supply: 100-240V~50/60Hz 4A 350VA 3. Output power supply: 33.6V, 9.0A, 302.4W 4. Standard battery charging time: 0.8h 5.Charging time of long-life battery: 1.5h
